|Input Voltage||10-30VDC||Power Dissipation||1.5 W max|
|Output Type||Solid State Relay||Output Isolation||400 V max|
|Voltage Switching Capacity||200VAC peak; 180 VDC||Current Switching Capacity||80mA AC load; 110mA @ 132VDC (derate-100mA @ 180VDC)|
|Off-State Leakage||10 µ max||On-State Resistance||25 ? max|
|Response Time||3 mS||Light/Dark Op||Specified by model #|
|Temp Range||Operating: -25°-+55° C; Storage: -25° – +70° C||Lens||Polycarbonate|
|Cable Jacket||PVC||Body||Structural Polyurethan Foam|
|Cable/Connector||6-foot cable, 4-wire; micro connector, 4-pin male||Vibration||30g over 10Hz to 2kHz|
|Shock||50g for 10mS 1/2 sinwave pulse||Sunlight Immunity||1,000 foot-candles|
|Indicator LED||Lights steady when output is ON||Enclosure Ratings||NEMA 1,2,3,4,4x,6,12, and 13|
|Approvals||UL and C-UL recognized, CE compliant||Sourse||Infrared, 880 nm|
|Max Range||8 inches (203mm)||Optimum Range||0.1-5 in (3-127mm)|
|Field of View||0.6 in (15mm) diameter at 5 in (127mm)|
Here is a Cutler-Hammer 13150RD07 SER A1 Prism Photoelectric R/A. Short circuit Protection: Protected (current limited) for loads less than 32 Volts AC or DC. IMPORTANT: Output will reset automatically when short is removed. (There is no visual indication of a short circuit condition). Ranges based on a 3 in diameter retroreflector. Retroreflector not included. Sensor will detect a 90% reflectance white card at this range.
